SK127

馬達: Shaded pole, impedance protected
外殼: Die-cast aluminum, Painted black (AP) or Plated (AN)
風葉: Glass reinforced thermoplastic, UL 94V-0
軸承: Two-ball or sleeve available
接電方式: T-Terminal push-on type or W-Lead wire type
耐壓: 1 min. at 1,500VAC, 50/60Hz
溫度範圍: Ball bearing -20℃~+70℃
Sleeve bearing -10℃~+55℃
壽命: Ball bearing 60,000 hours at 60℃
Sleeve bearing 20,000 hours at 45℃
淨重: 590gm (1.3 pounds)
檢定: UL, CUL, TUV, CE, RoHS
型號 電壓 頻率 電流 功率 轉速 最大風量 最大風壓 噪音
m3/min CFM mm-H2O inch-H2O
SK127AP-11-1 110
(100V~120V)
50/60 0.218/0.179 18.4/14.6 2700/3000 3.2/3.6 113/125 8.1/9.4 0.32/0.37 50/53
SK127AP-22-1 220
(200V~230V)
50/60 0.106/0.086 19.3/15.1 2700/3000 3.2/3.6 113/125 8.1/9.4 0.32/0.37 50/55
