馬達: | Single phase induction capacitor motor, thermally protected |
外殼: | Die-cast aluminum, Painted black (AP) or Plated (AN) |
風葉: | PC thermoplastic + glass fiber, UL 94V-0 |
軸承: | Two-ball bearing |
接電方式: | T-Terminal push-on type or W-Lead wire type |
耐壓: | 1 min. at 1,500VAC, 50/60Hz |
溫度範圍: | Ambient -20℃~+70℃ |
壽命: |
60,000 hours at 40℃ |
淨重: | 1013gm (2.23 pounds) |
認證: | UL, CUL, TUV, CE, RoHS |
型號 | 電壓 | 頻率 | 電流 | 功率 | 轉速 | 最大風量 | 最大風壓 | 噪音 | ||
m3/min | CFM | mm-H2O | inch-H2O | |||||||
SK170AP-11-1 |
110 (100V~120V) |
50/60 |
0.52/0.52 |
59/56 |
2675/3046 |
7.9/8.9 |
280/315 |
15.2/18.7 |
0.60/0.74 |
56/59 |
SK170AP-22-1 |
220 (200V~240V) |
50/60 |
0.26/0.26 |
59/56 |
2609/2960 |
7.9/8.9 |
280/315 |
15.2/18.7 |
0.60/0.74 |
56/59 |
